GOTECK GS-9018C Brush Micro Servo 9g 1.5KG for RC Models

GOTECK GS-9018C Brush Micro Servo 9g 1.5KG for RC Models
Eachine1
артикул: 1089003
СОГЛАСНО НАШИМ ДАННЫМ, ЭТОТ ПРОДУКТ СЕЙЧАС НЕ ДОСТУПЕН
$3.14
Доставка из: Китай
   Описание
Notice the color will change to blue but same specification GOTECK GS-9018C Brush Micro Servo 9g 1.5KG for RC Models Description: Brand: GOTECK Item: GS-9018C Servo Size(mm): 22*12*29 Torque: 1.5 kg/ 0.1sec @ 6V Weight: 9g Speed: 0.12-0.1 sec/ 60 GS-9018 Control System Positive PWM control 1500 usec Neutral Operation Voltage Range 4.8V ~ 6.0V Operation Temperature Range -20C~ +60C Test Voltage: At 4.8V At 6.0V Standing Torque 1.5kg.cm 1.7kg.cm Speed 0.3 sec / 60 deg at no load 0.12 sec / 60 deg at no load Idle Current 160mA at stopped 500mA at stopped Running Current 180mA at no load 600mA at no load Dead band width 8.0 s 8.0 s Circle 15000 times Operation Travel 6010 Direction Re-clock wise/ Pulse Travel 1500 to 2100 usec Motor Type Brush Potentiometer Type Direct Driver Amplifier Type Analog Control Dimensions 23*12.1*21.4mm Weight: 9g without splined horn Ball Bearing N/A Gear Material POM Case Material PC Connector Wire Length 250mm Connector Wire Gauge 26AWG heavy duty (JR Universal) Package Included: 1X GOTECK GS-9018C Brush Micro Servo 1X screw set
