GLFILL Dc12V Battery Capacity Monitor Lcd Indicator Lead Acid And Lithium Ion Indicator

Feature * Simulate battery power 7 grids will automatically decrease according to the battery power *The static test of the percentage of electricity is accurate and there are errors in the charging and discharging process **In the working state press the switch of the product to measure the battery voltage state the range is 10-100V * Sleep low power consumption 10UA (microamps) *Applicable battery: lithium battery lead-acid battery universal adjustable Specification 【Name】Battery level display board 【Model】JS-C32 【Display】LCD 【Protection features】Reverse polarity protection 【Working voltage】12V [Working power consumption] 5MA [Sleep power consumption] 10UA 【Power principle】Voltage type [Applicable battery] Lithium battery lead-acid battery is universally adjustable 【Backlight Color】Green Instructions 1. Insert the 30CM wire provided with the product into the reserved terminal position on the back of the product and pay attention to the direction of the buckle 2. The red wire is connected to the positive electrode of the battery to be measured and the black wire is connected to the negative electrode to ensure good contact 3. After the product is connected the battery level will be displayed press the button to switch to voltage and press the button to turn off the meter packing list: 1*meter 1*30CM wire
