GLFILL 5V 1/8Npt Air Fuel Pressure Sensor Stainless Steel Transmitter Sensor

Features: -It is an advanced pressure sensor than conventional mechanical pressure sensor. -± 2% FS small output error including non-linearity hysteresis and repeatability over temperature. - Has perfect surge protection function. - Light weight small size easy installation and operation. Specification: Product Name: Fuel Pressure Sensor Material: Stainless Steel and Rubber Color: silver and black Voltage: DC 5V Dimensions: 53mm x 14mm Cable length: 312mm Thread: 1/8 - 27 NPT / 1/8 NPT Pressure: 5psi 15psi 30psi 60psi 100psi 150psi 200psi - 30 psi Input: 0-30 psi Output: 0.5V ~ 4.5V linear voltage output. 0 psi 0.5V output 15psi 2.5V output 30 psi 4.5V output. Accuracy: Within 2% of reading (full scale). Thread: 1/8 -27 NPT. Wiring Connectors: Water-tight quick disconnects. Includes mating connector. Wiring: red means +5V; black means grounding; blue means signal output . --100psi Input: 0-100 psi Output: 0.5V ~ 4.5V linear voltage output. 0 psi output 0.5V 2.5V 50 psi output 100 psi output 4.5V. Accuracy: Within 2% of reading (full scale). Thread: 1/8 -27 NPT Wiring Connector: Water seal quick disconnect. Includes mating connector and harness (pigtail). Wiring: +5V red; black is ground; blue is signal output. -- 150 psi Input: 0-150 psi Output: 0.5-4.5V linear voltage output. 0 psi 0.5V output 75 psi 2.5V output 150 psi 4.5V output Accuracy: +/-0.5% FS Thread: 1/8 NPT Wiring: red is +5V; black is ground; green is signal output Overload capacity: 2-4 times rated pressure Working temperature: -40℃~+120℃ Compensation temperature: 0℃~+80℃ Protection class: IP67 Pressure medium: oil gas water compatible with 316L stainless steel Load resistance: ≤ (power supply -6.5V/0.02A) Ω. Long-term stability: less than 0.1%FS/year Zero temperature effect: Typical: 0.02% FS/℃; Effect of Temperature on Sensitivity: Typical: 0.02% FS/°C; Impact resistance: 1000g impact resistance : ≤ +/-0.01% FS (X Y Z axis 200 Hz/g) Response time: ≤1ms Insulation resistance: > MΩ VDC Class A explosion-proof: ExiaTTCT6 -- 200 psi Input: 0-200 psi Output: 0.5V ~ 4.5V linear voltage output. 0 psi output 0.5V 100 psi output 2.5V and 200 psi output 4.5V Operating temperature: -40 ~ +125℃ Accuracy: ±1% FS Thread: 1/8 -27 NPT Overload capacity: 2 times rated pressure pressure Medium: oil gas water compatible with 316L stainless steel Load resistance: ≤ (power supply -6.5V/0.02a) Ω Long-term stability: ± 0.2% FS/year Zero Temperature Effect: Typical: ± 0.02% FS/°C Effect of Temperature on Sensitivity: Typical: ± 0.02% FS/°C Impact resistance: 100g impact resistance : ≤±0.01% FS (X Y Z axis 200Hz/g) Response time: ≤1ms Insulation resistance: > MΩ VDC Explosion-proof grade: ExiaTTCT6 Electromagnetic compatibility: EN50081-1 EN50082-2 IEC6 1000-4-3 Wiring Connector: Water seal quick disconnect. Includes mating connector and harness (pigtail). Wiring: red is IN+; black is GND; OUT is green. Install: For oil fuel diesel gas air pressure (cannot be used to measure water pressure) Can be used for fuel tanks gas tanks diesel tanks etc. Package Included: 1 x pressure sensor (with cable)
