GLFILL 200-350 Grid Tie Inverter DC18-50V to AC230V for 36V Solar Panel Inverter

Features: *Made of high quality materials durable *Model: 200W 250W 300W 350W (optional) *IP65 waterproof design (installed at the bottom of the solar panel) *Communication data monitoring screen. *Built-in high performance Maximum Power Point Tracking (MPPT) function *Suitable for 2X250W-300W 36V solar panels (Vmp30-39V; Voc36-50V) *aluminum alloy. better cooling. *Supports single-phase or three-phase connection. *Easy wiring. *High precision phase detection; overvoltage and undervoltage protection; overfrequency and underfrequency protection; island protection. Product parameters: SG200MS: Inverter model: SG-200W MPPT voltage range: 24V-40V Working voltage range: 18V-50V Maximum input voltage: 50V Starting voltage: 18V Maximum input power: 200W Recommended solar panel: 200W Voc: 36-50V AC rated voltage range: 220V Rated output power: 195W Maximum output power: 200W Default output voltage range: 230VAC (180V-280V) Rated output frequency: 50Hz/60Hz automatic Maximum number of units per branch: 120VAC: 4 units / 230VAC: 8 units Waterproof grade: IP65 Communication: 2.4G wireless (without communication box) SG300MS: Inverter model: SG-300W MPPT voltage range: 24V-40V Working voltage range: 18V-50V Maximum input voltage: 50V Starting voltage: 18V Maximum input power: 300W Recommended solar panel: 300W Voc: 36-50V AC rated voltage range: 220V Rated output power: 295W Maximum output power: 300W Default output voltage range: 230VAC (180V-280V) Rated output frequency: 50Hz/60Hz automatic Maximum number of units per branch: 120VAC: 4 units / 230VAC: 8 units Waterproof grade: IP65 Communication: 2.4G wireless (without communication box) User notice: *Vmp (of the solar panel) must be within the MPPT tracking range to ensure good output efficiency *Use only the solar panel connected to this device. The device is an ON-GRID microinverter. In order for it to work it must be properly connected to the power supply and the power supply must be working properly. When the grid stops working it also stops generating electricity. *Do not exceed the voltage of the PV modules to exceed the maximum input voltage of the solar grid-tied inverter. (Vmp＞28V; Voc＜50V) *Do not exceed the maximum input power of the grid-tied solar inverter with the power of the PV modules. (2X300W) *The positive and negative poles of solar modules cannot be reversed. If you extend the solar panel cable. You have to be careful about this. *Install away from direct sunlight and rain (ventilated dry cool). Package Contents: 1 * Grid-tied inverter (optional) Notes: 1. Due to various factors such as display brightness and light brightness the actual color of the product may be slightly different from the website picture. 2. Please allow a slight deviation between the data and the manual measurement.
