GEPRC GEP-Pagoda2 5.8G 2dBi FPV Antenna SMA/RP-SMA RHCP/LHCP 6cm 60mm

Summary Pagoda 2 is based on Maarten Baert optimized circular polarized antenna Produced by GEPRC customize a 5 8 G antenna is the scope of its bandwidth of 500 MHZ 5 55 to 6 05 GHz Structure consists of three layers of 1 oz copper foil embedded PCB only 8 grams of weight use special heat shrink packaging solid durable and beautiful PCB materials used 1 0 mm FR4 1 oz copper foil Pagoda 2 has natural advantages axis ratio is below 1 3 standing wave ratio of 1 2 Can be used for transmitting antenna and receiving antenna transmit and receive all use pagoda2 antenna is better Specification Model GEP Pagoda2Net weight 9gGain 2dBiLength 60mmOperating frequency 5 8GHzBandwidth range 500MHz 5 55 6 05 GHz Match Return loss S11 20 dB VSWR 1 22 center frequency Axial Ratio 1 3Radiation efficiency 95 Interface type SMA RP SMAPackage Included 1 x GEPRC Pagoda 2 5 8GHz AntennaNote The blue antenna is LHCP green antenna is RHCP
