GAT-16

GAT-16 sebuah 802.3at (Active) injector dengan 16 Gigabit port.
Mampu memberikan daya ke 16 perangkat up-to 25 watts / port desain 1U fanless.
• 16 Port 802.3af / at compliant Gigabit Ethernet Injector
– 16 Shielded RJ-45 LAN
– 16 Shielded RJ-45 LAN+POE
– PoE status LED for each jack
– all 4 data pairs active for gigabit data rates
– shared data and power via transformer power injection on 12 – and 36+
– pins 45 78 pass thru without modification
• 1U high standard rack mount ( 1.75 x 19 x 2 inches)
• 315 current limiter per port per 802.3af specifications
• 650 ma current limiter per port per 802.3at specifications with a 802.3at load
• No power is supplied to non-PoE devices
• Same voltage to all ports
• Dual power supply inputs with relay failover/ load balancing.
• 2 LEDs for input power display
– one per input Green
– 48 volts, Amber
– 56 volts
• 16 LEDs for per port PoE mode display. Blue if a PoE device is connected
• Use with any Ethernet switch – passes all management info transparently
• Ideal for IP Cameras, VOIP phone, WiFi Access Points with 802.3af or 802.3at
• Technical support world wide
• Power supply range 48 to 56 volts via 2.1mm x 5.5mm input ( 2 )
• Additional Phoenix DC connector
- 3.5mm model 1844236 - pin 1,2 (minus) 3 (plus)
Environmental :
– operating temperature range – 0 to 50 deg C
– storage temperature range – 0 to 50 deg C
– relative humidity range – 5 to 90% non condensing
– FCC rules – there are no RF emitting devices in the design
– the device is PELV per NFPA standard 79 – protected extra low voltage
– no cooling is required, no fans. Quiet operation with no moving parts **UNTUK MENGAJUKAN PROSES PENGADUAN DIKARENAKAN KERUSAKAN BARANG / KEKURANGAN KELENGKAPAN DAN SEJENISNYA MOHON SERTAKAN VIDEO UNBOXING, KLAIM GARANSI MELALUI WEBSITE CITRAWEB.COM**
