Fugacal FT232 Module USB To Serial TTL Adapter Upgrade Download Flash Board FT232BL/RL Luxury Gold USB To Serial Module USB To TTL Serial Adapter

Feature: 1. Original FT232BL Industrial Grade Chip: Using the original FT232BL industrial grade chip the external EEPRON(93C46) is more stable 2. 3 Power Supply Modes: Support 3 power supply modes of 5V external power supply; 3.3V external power supply; external power supply(requires 3.3V-5V) 3. 3 LEDs: FT232 module support 10 come with 3 LEDs that is TXD LED RXD LED and POWER LED 4. Out By Curved Pins: GND RXD TXD 3V3 5V is out by curved pins and other functions PIN is reserved pads CTS RTS 5. 500MA Self Recovery Fuse: USB to TTL adapter come with 500MA self recovery fuse reverse connection will not burn Specification: Item Type: FT232 Module Applications: RS-232 traditional device upgrade to USB USB to RS-232 serial adapter Package List: 1 x FT232 Module 1 x Cable Note: Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering. How to use: How To Use: (take access to MCU as an example) GND: Connect to GND RXD: Connect To MCU.TX (signal flow: MCU.TX >> FT232 >> PC.RX) TXD: Connect To MCU.RX (signal flow: MCU.RX > FT232 >> PC.CTS)
