For.A MV-1210 3G/HD/SD/Analog/HDMI/DVI Mixed High Resolution Multi Viewer

Supports mixed signals including: 3G-SDI (Level-A/B), HD-SDI, SD-SDI, Composite, HDMI or DVI sources. Asynchronous input is also supported. The multi viewer accepts an array of formats and frame rates including NTSC, PAL, 1080/59.94i, 1080/50i and 30/29.97/25/24/23.98p or PsF. (No frame rate conversion) Up to 16 input channels with optional cards (SDI and HDMI inputs total) Combine optional input cards, MV-12SDI (3G/HD/SD-SDI, Composite x 4), MV-12PCI (DVI/HDMI x 4) or the MV-12IF interface card (GPIO, serial control, LTC input, genlock), as needed. 3G-SDI inputs support 4K (UHD) source input Layout Manager enables easy layout of 4K video in a seamless display HDMI 2.0b output, using MV-12PCO 4K UHD output via one HDMI cable (3840 x 2160 YUV 4:2:0) Logo display in title areas Import a bitmap from the logo registration screen or generate and register a logo using a web browser. Layout Manager Customize layouts, using the software in Windows to adjust image size, position, title display and other settings. Store layouts on the viewer. Recall saved layouts directly from the front panel control. Video Streaming In addition to computer-based layout management, video can be streamed from the multi viewer over Ethernet. Streamed video can be viewed locally via Ethernet, using a computer display as a secondary monitor. Remote monitoring is also supported. Record Streamed Video Take streaming a step further by capturing the video. Frames before and after errors or specified triggers are captured and can be saved to a Windows computer as still-image sequence files. Audio Level Monitor up to 16 channels of audio levels in each 3G/HD/SD-SDI or HDMI signal. Use Layout Manager to customize display positions, number of channels and display groups. Audio Monitoring Output Audio from any channel can be monitored via 3G/HD-SDI, HDMI or analog audio output. Prominent Error Display Errors can be displayed using flashing borders, error icon or error messages identifying the relevant frame. Error triggers include:Video loss, frozen frames, incorrect luminance/black levels, CRC errors, HDCP errors, audio loss, silence and excessive audio levels Tally/Title/Timecode • Tally: Frame tally and marker tally display • Titles: Identify each source channel with a title. Supports display of alphanumeric characters, symbols and Korean characters (up to 16 letters), which can be displayed within or outside the picture. The multi viewer can convert and save the characters typed on a computer as a logo in bitmap format for later use on the viewer screen. • Timecode: Ancillary Timecode in 3G/HD/SD-SDI signals can be displayed. Time of day, Timer and Information Display The multi viewers support clock time synchronization with SNTP servers. Up to 8 clocks can be displayed in analog or digital format. Date display is also available. The Date display feature can be used as a count up/down timer, remaining time counter, schedule timer or for information display. Information Display Information for display includes error logs from each window, user-entered text and multi viewer information. Logo/Background Up to 8 logos can be added. Backgrounds can be added to each of the 4 outputs (1 outputs in 4K operation.) Input Lock Input lock for each of the standard inputs enables genlock without using reference signals. Can display time based on a 30-hour clock Time display can begin at 6 a.m., with midnight to 5 a.m. as hours 24 to29 in a 30-hour period. Settings between 24-hour and 30-hour clocks are made in 1-hour increments. Schedule Timer As a trigger to display the remaining time, up to 24 times can be scheduled per day, on each week day. Import and export schedule timer files as needed. Cropping Specify areas to crop from any side of a window in pixels or by percent. Background image is shown outside cropped areas. Aspect ratio also maintained after partial cropping (of one side, for example). Sides can be extended after cropping, to enlarge the display. Frozen Frame Detection To enable the multi viewer to respond to changes in chroma, depending on the yield, due to data compression or expansion, Y/C or Y alone can be detected.
