For.A 3G/HD/SD/Analog/HDMI/DVI/RGBHV Mixed High Resolution Multi Viewer

The MV-4200 is a 2U multi-viewer that accepts up to 68 channels of mixed 3G/HD/SD-SDI, analog composite, HDMI, DVI or RGBHV signals for monitoring on 8 screens. Full-featured, this unit offers a customizable window layout, audio level meters and AFD-compatible cropping. Up to 68 channels of input with optional cards Combine optional input cards-an MV-4200SDI card (3G/HD/SD-SDI, analog composite x 20) or MV-4200HDMI card (DVI-I/HDMI/RGBHV x 8)-or the MV-4200IF interface card (GPIO, serial control and input of analog audio, AES audio and genlock) as needed View up to 8 monitors in different layouts • Up to 114 windows for 8 channels • Up to 8 clocks for 8 channels • Up to 8 logos and 1 background per output Use 4K sources by using four 3G-SDI inputs Layout Manager enables easy layout of 4K video in a seamless display Layout Manager A Windows based application is provided for managing and creating screen layouts. Customize the layout on a computer by registering or changing layout patterns, adjusting title displays and configuring other settings as needed. Store up to 68 layout patterns on the viewer. Saved layouts can be applied directly from the front panel control. Video Streaming In addition to computer-based layout management, you can also stream video from the viewer over Ethernet. The streaming video can be used for additional local computer displays or for remote monitoring applications. Record Streamed Video Take streaming a step further by capturing the video. Frames before and after errors or specified triggers are captured and can be saved to a Windows computer as a sequence of still-image files. Versatile Mixed-Source Environment Supports mixed signals as required, from 3G-SDI (Level-A/B), HD-SDI, SD-SDI, analog composite, HDMI, DVI or RGBHV sources. Asynchronous input is also supported. The viewer accepts an array of formats and frame rates including NTSC, PAL, 1080/59.94i, 1080/50i and 23.98/24/25/29.97/30 P or. PsF. (No frame rate conversion.) HD Output of Source Signals Up to 8 channels of output, each with HDMI and SDI interfaces available for HD monitoring support. Audio Level Monitor up to 16 channels embedded audio levels in each 3G/HD/SD-SDI or HDMI signal. Use Layout Manager to customize display positions, number of channels and display groups. Audio Monitoring Output Audio from any channel can be monitored via HD-SDI, HDMI or analog audio output. Prominent Error Display Indicates errors by full-screen display, flashing border, error icon or error message prominently identifying the relevant frame. Tally/Title/Timecode • Tally: Choose from frame tally or marker tally display • Titles: Identify each source channel with a title. Supports display of alphanumeric characters, symbols and Korean characters (up to 16 letters), which can be displayed within or outside the picture • Timecode: Ancillary Timecode in 3G/HD/SD-SDI signals can be displayed Time and Timer Display Supports clock time synchronization with the SNTP server. Up to 8 clocks can be displayed in analog or digital format. Date display is also available. This feature can be also used as a count up/down timer or remaining time counter. Logo/Background Register up to 8 logos. Up to 2 in 4K size or 8 in 2K size background images can be registered. Add 8 logos in total and one background image per output, as required.
