For Raspberry Pi CM5 WAVESHARE Gigabit / 2.5G Dual Network Port Expansion Board Support Access To RJ45 And Dual 4K Outputs US Plug

For Raspberry Pi CM5 WAVESHARE Gigabit / 2.5G Dual Network Port Expansion Board Support Access To RJ45 And Dual 4K Outputs US Plug
WAVESHARE
sku: 4097557
$68.28
Shipping from: China
   Description
1. CM5 card holder: for all versions of Compute Module 52. Networking: 1000M Ethernet RJ45 interface, 2500M Ethernet RJ45 interface3. Connector: Raspberry Pi 40PIN GPIO interface4. USB: USB 3.2 Gen1 x 1, USB 2.0 x 4. USB: USB 3.2 Gen1 x 1, USB 2.0 x 25. MIPI: 4-lane MIPI interface x 2 (22PIN 0.5mm FFC connector)6. Video: HDMI connectors x 2, supports dual 4K outputs7. M.2: M.2 M KEY (PCle Gen2/3 x 1)8. Storage: on-board Micro SD card slot (for CM5 version without eMMC)9. Others: on-board EEPROM and encryption chip10. Fan interface: 5V, 4PIN JST-SH PWM fan connector11. Power input: 7V - 36V wide voltage12. Size:- Base plate: about 10.9 x 9.15cm- Case: about 11.46 x 9.15 x 3.29cmFeatures:1. 40PIN GPIO interface and standard CM5 connector on board, support access to Compute Module 5 Lite / eMMC series core boards2. Support M.2 NVMe hard disk, greatly improve the read and write speed of the system or file, support NVMe SSD boot3. Equipped with ETH / MIPI / HDMI / Micro SD / USB / M.2 B KEY / M KEY and other interfaces, more convenient to use4. Careful hole design ensures that each port can fit the motherboard with a high degree of accuracy, and the ports are labeled with a clear silkscreen for easy viewing5. Shell top vents reserved for better heat dissipation6. Wall-mounted holes on both sides of the design, more convenient to install and fix, in the back of the reserved rail mounting screw holes, you can fix the rail (not included)Packing list:- Expansion board x 1- Metal casing x 1- Fan x 1- Power cord x 1- Plug x 4- Screws x 9
