For MACH 3 Edge Finder 3D Probe Used for Cnc Milling Machine Photoelectric Sub-Center Rod
Описание
Common problems and improvement methods 1. Data cable connection definition. The red wire is 10 (signal) the white wire is GND and the yellow wire is 0V (GND). 2. Whether to open the spindle speed when probing. A. The edge finder is designed to withstand up to 600 rpm rotation and high-speed rotation will damage the edge finder. 3. When the data cable is connected for automatic detection the spindle cannot be opened the rotation will break the data cable and damage the edge finder. C. When the data cable is not connected and it is simply used as an acousto-optic centroid turn on the spindle to rotate at a speed of 600 rpm.Probe directly without opening the spindle. 3. How to judge whether the homing position of the edge finder is accurate after the trigger signal? After the edge finder is installed on the chuck turn the meter to 0 push the probe by hand and after the probe is automatically returned rotate the edge finder to see. Whether the table value is a constant value. 4. Why is the concentricity different after the precise edge finder is re-installed on the spindle and chuck? Each time the edge finder is reinstalled it is affected by the concentricity of the main shaft and the collet and the concentricity deviation of the main shaft and the collet will cause. The concentricity of the edge finder probe is offset. How to improve the detection accuracy when the numerical control system of machine tool mechanical structure accuracy cannot be further improved. A. Rotate and divide by the spindle speed of 600 r/min (this method can only be used for offline work without connection if you need to rotate the edge finder. Automatic centring detection you can purchase a wireless edge finder to achieve) B. The deviation of the main shaft and the collet can be adjusted by marking the 0 position of the edge finder on the main shaft and the collet and search for each installation. The fixed position and orientation of the edge gauge relative to the central head and main shaft is improved. (The most fundamental solution is to improve Spindle and collet accuracy) The signal processing response time of the edge finder is fixed at about 0.0005±0.0001s but various grades of numerical control systems and A set of circuits the delay consistency difference is relatively large. When the probe approaches the measured surface reduce the axis movement speed as much as possible. In order to reduce the error caused by the delay consistency problem. Outer diameter of edge finder|mm|39 Clamping diameter|mm |6| Clamping length|m|Less than 20 Repeatability|mm|0.01 XY Pendulum|mm |3 Exceeding the stroke will cause damage 2 Pendulum pairs|mm |1.5 Exceeding the stroke will cause damage Battery||Lithium battery online automatic charging Work offline||Can be used as a photoelectric splitter Online work||Cocoa with the system for automatic centering Connection method||Distribution data cable|2m probe|mm|p1 tungsten steel Probe|mm|Competing for 1.5 Ruby Waterproof rating||IP43 can not work in the environment of coolant spraying Working voltage|V|6-30 overpressure out low voltage can t work Colour: Black material: metal Package Contents: 1 x Edge Finder Probe 1 x wrench 1 x cable
