Feiruifan Durable Useful Easy to Install 12-40V DC Potentiometer CCMHCW PWM Motor Speed Controller Regulator with Knob

Specifications: It features 12-40V wide voltage 8A. Can not input 220V household electricity. DC motor speed controller allows you to control the speed of a DC motor with a pulse width modulated (PWM) DC voltage with a duty cycle. Item Name: DC Motor Speed Controller Material: PCB Model: CCMHCW Potentiometer: Resistance Value B100K Wire Length 20cm Opening 8mm Working Voltage: DC12V-40V Control Power: 0.01-400W Applicable Current: Rated Current 8A Maximum Through Current 10A Quiescent Current: 0.02A (Standby State) PWM Frequency: 13khz PWM Pulse Width Speed Regulation Range: 10%-100% Output Voltage: about 0-100% of Input Voltage Control Power: 12Vx8A=96W 24Vx8A=192W 40Vx8A=320W Rated Current: 8A Maximum Current: 10A Speed Adjustment Range: 10%-100% PWM Frequency: 13kHz Features: Durable Useful Easy to Install Size: 6cm x 5.5cm x 2.8cm/2.36 x 2.16 x 1.1 (Approx.) Notes: Due to the light and screen setting difference the item s color may be slightly different from the pictures. Please allow slight dimension difference due to different manual measurement. Package Included: 1 x DC Motor Speed Controller
