Fdit RF Mixer Module High Frequency Mixing Board 0.1‑500MHz Electronic Component AD831 RF Mixer Module RF Mixer Board

Feature: 1. RF MIXER MODULE: This RF mixer module is used processing the RF signal amplified by LNA with high efficiency. 2. NO INSERTION LOSS: No insertion loss neither external duplexer nor passive termination is required very easy to use. 3. LOW DC BIAS: Used DC coupling in DC baseband frequency conversion and quadrature amplitude demodulation. 4. WIDE APPLICATION: RF IF down conversion in HF and VHF second mixer in base stations and so on. 5. GOOD MATERIAL: Adopting premium Printed Circuit Board material the durable RF mixer module is not easy to break. Specification: Item Type: RF Mixer Module Material: Printed Circuit Board Model: AD831 RF Input: 0.1-500MHz RF Input: +10dBm (1dB compression point) Local Oscillator Input: 0.1-500MHz (-10dBm) IF Output: 0.1-200MHz Power Supply Voltage: DC 9-11V single ended power supply. Function: Used to process the RF signal amplified by LNA. Applicable Scenarios: Suitable RF IF down conversion in HF and VHF second mixer in base stations DC baseband frequency conversion quadrature modulation and demodulation and Doppler frequency shifting detection in imaging And other applications. Package List: 1 x RF Mixer Module Note: Do not use in an electrostatic environment otherwise it will damage the electronic components.
