Famure Non-Contact Water Level Sensor|low Pressure Side Mount Horizontal Water level Sensor|Liquid Level Sensing Float Switch Witch Wire Cable for Tank Pool

Features: Installation method: bracket fixed installation Non-contact liquid level sensors can only be installed and used in non-metallic containers or pipes such as PP glass and ceramics.Installed on the outer wall of the container it does not need to be in direct contact with the liquid to be measured and will not be corroded by strong acid and alkali liquids nor affected by scale. After installation due to the different thickness of the container if you need to adjust the detection sensitivity of the sensor you can lift the QC label fix the sensor on the container or pipe under test adjust the liquid level to the position that needs to be sensed and then press the small circle. Press the button in the hole for about 3 seconds until the blue status indicator flashes then release the button and the liquid level can be sensed when the liquid level rises and falls near this position. Switch model: WS03M Switch name: non-contact liquid level sensor Working voltage: DC5-24V Output voltage Vol (Lo): 0.5V Output current Iol (Lo): 300mA Current consumption: 5mA Response time: 0.5 seconds Operating temperature: 0~60Celsius Switch cable length: 1.5m Bracket type: A type/B type/C type (A plane bracket B tube diameter 8-12mm/0.03-0.04ft bracket C tube diameter 12-26mm/0.04-0.09ft bracket) Size: length width and thickness 30*19*10mm/1.18*0.748*0.39 ft Packing list: 1*Non-Contact Water Level Sensor
