FX3U 48MR RS485 (Real Time Clock) 24 Input 24 Relay Output 6 Analog Input 2 Analog Output Plc Controller

Specifications: Input Voltage:DC24V Output Point Y component: Y0-Y17 are transistor output. Y0~Y7 can output 8-channel 100K pulse or 6-channel PWM pulse signal. Maximum current is 3A. Y0-3 are high-speed output port (max. 100k). PWM period is 0-32767US. High-speed port maximum current is 3A. External load common end connects to +24 the other end connects to PLC output port Y. Analog Input: 6 channels analog input 12-bit accuracy; 3-channel 0~10V+3-channel 0~20mA read with RD3A Analog Output:2 channels analog output 12-bit accuracy output voltage:0-10V. Output analog voltage with WR3A Intermediate Relay M:M0-M3071 power-off save range can be set Stepping Point S:S0-1023 power-off save range can be set S0-S1023 100Ms Timer:T0-T199 accumulative power-off save T184-T199 10Ms Timer:T200-T249 accumulative power-off save T246-T249 1Ms Timer:T250-T383 T250-255 is accumulated type 16-bit Counter:C0-C199 power-off save C100-199 32-bit Counter:C200-C219 power-off save C220-C234 32-bit High-speed Counter:C235-255; C235-240 is single-phase counter no frequency Colour:green Material:plastic Package Contents: 1 * plc industrial control board Only the above package content other products are not included. Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
