FTTH Fiber Optic Cable Tester Tool Kit with Fiber Cleaver/Power Meter/Stripper/Fault Locator

Name:FTTH Fiber Optic Tool Kit with Fiber Cleaver/Power Meter/Stripper/Fault LocatorSpecifications:Name:optical fiber cleaverMaterial : Metal+PlasticPackage Size:35 x 26 x 10cmfiber diameter:125umCleave length:9-16mm(F0.25 10-16mmF0.9 Size:65 x 63 x 61mmThis FC-6S optical fiber cleaver is available with a single fiber adapter for 250 to 900 micron coated single fibers.It is a simple operation for the user to remove or install the single fiber adapter and alternate between mass and single fiber cleaving.Operation:Please lift the optical fiber plate cover open and close rod,make sure the position of the blade, blade slot and cutting position.Place the optical fiber to be cut in the loading slot.3.Close the ptical fiber plate cover v release the close an open rod,push the blade slide rod,cut the optical fiber. Optical Power Meter:Specification:Wavelength800 ~1700 nmDetectorInGaAsMeasurement Range-70~+3 dBmUncertainty±5% (-10 dBm,20±30C)Calibrated Wavelength850,980,1300,1310,1490,1550,1625 nmResolution0.01 dBmConnectorFC ,SC ,LCPower SupplyAlkaline Battery(2 AAA 1.5V not included)Battery Operating Time=48HOperating Temperatrue-10~+600CStorage Temperatrue-25~+700CRelative Humidity0~95% (non-condensing)Dimension180 x 86 x 47mmButton Introduce:Close/Open ButtionPress this button for 1 second ,it will open,press again,it will close.AUTO/OFFPress this button can close or open automatically close function,the LCD upper left corner will display the prompts at the same time.ZEROThis button can implementation automatically cleared.LIGHTThis button can be turned off or open the background light, the LCD upper left corner at the same time display the prompt.Db Can make the relative measurement of the optical power at the corresponding wavelength?Can choose 7 different wavelength(850,980,1300,1310,1490,1550,1625 nm)Calibration instruction:1.Press ? and LIGHT button at the same time,(press again will exit the calibration mode.)then press LIGHT button one time plus 0.05dB,press dB button one time reduce 0.05dB.After adjustment,press ZERO button to save open the machine again.2.Press ? and ZERO button at the same time can restore the factory Setting. Package include: 1 x FC-6S Optical Fiber Cleaver 1 x DBF Handheld Optical Power Meter 1 x 1mw Red Light Visual Fault Locator 1 x FCS-2 Plier 1 x Cable Stripper 1 x Vise 1 x Fiber Optic Shears 1 x Diagonal Plier 1 x Nipper Plier 1 x 2 In 1 Fixed-Length Guide Rail Strip 1 x Plastic Box 1 x Alcohol Bottle 1 Set Swab 1 x Air-Laid Paper 1 x Big Knife Adjustable Tool 1 x Middle Knife Adjustable Tool 1 x Small Knife Adjustable Tool 1 x Optical Power Meter SC Adapter 1 x Optical Power Meter SC Adapter(Have Installed In The Optical Power Meter) 1 x Guide Rail Strip 1 x Screwdriver 1 x Storage Box 1 x Strap 1 x Optical Power Meter Bag 1 x Fiber Cleaver Bag ,,,,,,,,,
