FT4232HL High-speed USB Transfer Serial Module Complete Demo USB2.0 Data Acquisition Module Development Board

Overview The FT4232H is FTDIs 5 th generation of USB devices The FT4232H is a USB 2 0 High Speed 480Mb s to UART MPSSE ICs The device features 4 UARTs Two of these have an option to independently configure an MPSSE engine This allows the FT4232H to operate as two UART Bit Bang ports plus two MPSSE engines used to emulate JTAG SPI I 2 C Bit bang or other synchronous serial modes Features Single chip USB to quad serial ports with a variety of configurations Entire USB protocol handled on the chip No USB specific firmware programming required USB 2 0 High Speed 480Mbits Second and Full Speed 12Mbits Second compatible Two Multi Protocol Synchronous Serial Engine MPSSE on channel A and channel B to simplify synchronous serial protocol USB to JTAG I 2 C SPI or bit bang design Independent Baud rate generators RS232 RS422 RS485 UART Transfer Data Rate up to 12Mbaud RS232 Data Rate limited by external level shifter FTDIs royalty free Virtual Com Port VCP and Direct D2XX drivers eliminate the requirement for USB driver development in most cases Optional traffic TX RX indicators can be added with LEDs and an external 74HC595 shift register Adjustable receive buffer timeout Support for USB suspend and resume conditions via PWREN SUSPEND and RI pins and so on More details click to download FT4232HL Package Included 1 x FT4232HL High speed USB Transfer Serial Module
