FT232 USB To TTL Adapter Module Serial Download Brush Plate FT232BL/RL

Features: - Using the original FT232BL industrial chip, the external EEPRON (93C46) is more stable. - Support Windows 10 - Support three power supply modes: 5V external power supply; 3.3V external power supply; external power supply (3.3V-5V required) - 3led: txd led/rxd led/power point - GND, RXD, TXD, 3V3, 5V: use curved pin to lead out. - Other functions: reserved pin pads cts, rrt - With 500MA, self recovery fuse does not burn. Application Case: - RS-232 traditional devices upgraded to USB - USB to RS-232 serial adapter Instructions for Use: (for example, access to MCU) GND: connect GND RXD: connect MCU.TX (signal flow: MCU.TX FT232 PC.RX) TXD: connect to MCU.RX (signal flow: MCU.RX FT232 PC.TX) 3V3/5V: output 3.3V or 5V (module is powered by USB, and jumper cap must be jumped to 3.3V or 5V). RTS: connect to MCU.CTS (signal flow: MCU.CTS FT232 PC.RTS) CTS: connect MCU.RTS (signal flow: MCU.RTS FT232 PC.CTS) Package Included: 1 x FT232 USB To TTL Adapter Module
