FRF3_EVO_BRUSHED Flight Controller Built-in Frsky 8CH Sbus Receiver For Eachine QX95 QX90 QX90C

FRF3_EVO_BRUSHED Flight Controller Built-in Frsky 8CH Sbus Receiver For Eachine QX95 QX90 QX90CDescription:Brand Name: EachineItem Name: FRF3_EVO_BRUSHED Flight Controller Built-in Frsky ReceiverItem NO.: QX958FRDimension: 22mm*32.5mmThickness: 1.2mmWeight: 3gReceiver: Frsky 8CH sbus receiver(D8 mode)Coreless motor plug: SH1.0Firmware: SP RACING F3 EVO 1.13.0Support work voltage: 3.6v~4.2v(1S Lipo battery)Features:1.F3_EVO_Brush revision is out of the F3 EVO SP RACING is based on a SP RACING F3 EVO firmware 32 brush flight control.2.Independent design of the circuit structure3.Using STM32F303CCT6 + MPU6500, advanced hardware platform F3 guarantee more stable flight.4.With a large and high quality current NMOS transistors, operating current of up to 10A or more. Each Brushed motor is equipped with freewheeling diodes.5.Integrated 2.4G Frsky 8CH sbus receiver(D8 mode).6.With battery voltage detection and buzzer interface(solder pad)7.LED_STRIP Function(solder pad)Connection diagram:Receiver configuration:Enable Seria_RX for UART2 and Set Receiver mode RX_SERIAL ,Select SBUS in Cleanflight or Betaflight configurator.Bind procedure:1.Turn on the transmitter , select D8 mode for the Receiver.2.Connect the battery to the board while Jumped the two BIND pins on the Board, the green LED will get be solid, this indicates the receiver get into the binding mode.3.Move to the Receiver [Bind] option in the transmitter and ENT to Bind with the receiver, The transmitter beeps.The green LED
