FNIRSI-1C15 Professional Digital Oscilloscope 500MS/s Sampling Rate 110MHz Analog Bandwidth Support Waveform Storage

Description FNIRSI 1C15 is a fully functional practical and cost effective handheld oscilloscope newly launched by FNIRSI The real time sampling rate is 500M and the analog bandwidth is 110MHz In addition to all the functions of a conventional handheld oscilloscope we also added a one key quick auto function on this basis so you can easily grasp the waveform like a desktop computer We have added 1k Hz self test square wave for FNIRSI 1C15 and the storage depth has been upgraded to 12kpts With reference to the waveform you can pausie at any time to save the previous frame waveform to the screen and you can compare it with the currently refreshed waveform Afterglow and scroll modes make it easier to detect and record waveforms Built in 3000mAH rechargeable battery it can work continuously for more than 10 hours after fully charged The body is equipped with a high quality silicone sleeve which is non slip and anti drop The joystick replaces the original arrow keys making the operation simpler and more effective Product parameters Model FNIRSI 1C15Number of channels 1Screen size 2 4 inches Screen Resolution 320 240 Analog bandwidth 110M Sampling Rate 500M 1k Hz self checking square wave Stand by Rise Time 3ns Storage depth 12 Kpts Time base range 5ns 10s Vertical sensitivity 20mv div 100v div Trigger mode Auto Normal Trigger type Rising Falling Display mode YT scroll Afterglow time None 1s ∞ Charging method 5V 800mA Voltage measure
