FA-2 1Hz-12.4GHz Frequency Counter Kit Frequency Meter Statistical Function 11 bits/sec Tester with Power Adapter

Manual Click here to openSpecifications Model FA 2Data Types of Statistical Pattern Average Max Min P PPower Supply DC11 7 12 5V Start 0 4A Stabilize 0 2ASize 106 x 55 x 105mm L H D Weight 350g Introduction of CH1 CH1 Frequency 1Hz 300MHz CH1 Input Impedance 50 OHM 1M OHM CH1 Input Sensitivity Reference 50 OHM 25mVrms 2Vrms 1MR 25mVrms 2Vrms CH1 Frequency Accuracy 0 1s Gate Time 0 001Hz 10M 1s Gate Time 0 0001Hz 10M 10s Gate Time 0 00001Hz 10M CH1 Test Speed 11 bits second 10MHz CH1 Power Test Range 50DBM to 20DBM 1M to 550M 50 OHM CH1 Power Test Accuracy 0 5DB 10MHz CH1 Connector Type BNC Introduction of CH2 CH2 Frequency 30MHz 12 4GHz CH2 Input Impedance 50 OHM CH2 Frequency Accuracy 0 1s Gate Time 1Hz 1GHz 1s Gate Time 0 01 Hz 1GHz 10s Gate Time 0 001 Hz 1GHz CH2 Input Power 20dBM to 13dBm 0 5 to 5G CH2 Connector Type SMA Operating Modes CH1 Frequency Test Mode CH1 Statistical Pattern CH2 Frequency Test Mode CH2 Statistical PatternFunctions of Front Panel MODE Change operating modes GATE Change gate time RST Start to test again CH1 Channel 1 input CH2 Channel 2 input Functions of Rear Panel 10M REF INPUT External 10M input reference 10M REF OUTPUT 10M output reference USB USB port STD ADJ Internal OCXO frequency fine adjustment ON OFF Power switch 12V IN DC portPackage Included 1 x Frequency Counter 1 x
