Exalux CONNECT+ Dual Band Wi-Fi to DMX Gateway Kit w/2x TX100N DMX Transmitter

EXALUX offers the CONNECT+ Full Wireless DMX 2U kit to demanding gaffers who are looking for a turnkey solution to remotely control Lumen Radio CRMX compatible lighting fixtures with an iPad. The CONNECT+ Full Wireless DMX 2U gives you full wireless control of all Lumen Radio CRMX wireless products from your iPad. It is provided with a robust and waterproof case.- CONNECT+ Dual Band Wi-Fi to DMX Gateway -EXALUX CONNECT+ is a dual band Wi-Fi to DMX gateway that allows wireless lighting control via Art-net compatible App. CONNECT+ is compatible with the most of DMX Apps (BlackOut, DMX CONNECT+, Luminair).
CONNECT+ is certainly the most sophisticated Wi-Fi to DMX gateway on the market!
Cases of UsesEXALUX CONNECT+ is simply amazing. Everything is possible with CONNECT+ such as controlling your lighting fixtures with an iPAD or an Art-Net/sACN console, controlling HUE lamps, controlling NYX lamps.

Connect your TX100N CRMX transmitters to the XLR 5 outputs and control up to 2 DMX universes in wireless mode. The TX100N can be connected directly to the CONNECT+ or a few meters away using a specific DMX cable.

EXALUX CONNECT+ is really versatile. The new EXALUX SnapLink extension port will make it easy to add new features such as a DMX splitter or DMX recorder. EXALUX CONNECT+ can also be used as an Art-Net/DMX Nod and be remotely powered using a PoE injector.
Product Advantages
Dual Band Reliable Wi-Fi
EXALUX CONNECT+ features an high performance dual band (2.4Ghz+5Ghz) MiMo Wi-Fi Access point. This means you can be sure to have a reliable and responsive connectivity between your IPAD and your CONNECT+. Switch the 5Ghz Wi-Fi to use your CONNECT+ with a CRMX transmitter such as the TX100N and avoid any interference, or use it if the aera really is to noisy. In addition, EXALUX CONNECT+ features a mode that makes it possible to automatically select the clearer frequency band.
Wireless ScalabilityPlug your EXALUX CONNECT TX100N wireless DMX transmitters to the XLR 5 outputs to create a wireless DMX link between your iPAD and your lighting fixtures. The CONNECT TX100N can be connected directly to the CONNECT+ or a few meters away via a DMX cable to get the best connection. Thanks to the PoD, no extra power supply is needed.
2 Universes - 2 DMX Outputs
EXALUX CONNECT+ pushes the limits of DMX. CONNECT+ makes it possible to manage two DMX universes without adding additional interface, and thus, meet the needs of the most complex fixtures. In the near future, it will become possible to manage more than two DMX universes with the additional Connect interface. CONNECT+ is really clever to control your ASTERA NYX bulbs at your fingertips for example !

Fully Compatible with The Most Popular AppsWith EXALUX CONNECT+, you can now finally get the full potential of the most populars Apps such as BlackOut and Luminair. EXALUX CONNECT+ is fully compatible with all DMX applications based on the Art-Net protocol.
A Future-Oriented Power Supply ModeEXALUX CONNECT+ can be powered via the Ethernet cable using a PoE injector. This allows the CONNECT+ to be installed in the best place without worrying about power supply constraints. PoE mode is particularly useful if you use the CONNECT+ as an Art-Net Nod with a live hardware console. Thanks to PoD (PowerOverDMX) technology, you will be able to power additional DMX devices by connecting them directly to the 5-pin XLR connector.
Philips HUE ReadyConnect your Philips HUE Bridge to one of the RJ45 ports of the EXALUX CONNECT+ and control your Philips HUE bulbs with your iPAD. (The Philips HUE bridge is not supplied with the CONNECT+)
Upgradable, Backup-ableEXALUX CONNECT+ firmware can be updated using an USB stick. You will be able to get the latest improvements without worrying about the obsolescence of the unit when you buy it.
A Tiny Recorder on BoardEXALUX CONNECT+ features a tiny DMX recorder. This makes it possible to record a small sequence from the iPad and play it back later.
Safety Wi-FiEXALUX CONNECT+ supports a wide range of Wi-Fi protection such as WPA2 to ensure maximum security. In addition, the settings of the unit can be locked and saved on a USB key. It especially convenient for rental companies who can thus easily set up units before each rental.

Wide Range Power ModesThanks to its wide supply range (+5 to 28VDC), EXALUX CONNECT+ can be powered with a V-Lock battery, an external PSU or a PoE Injector. EXALUX CONNECT+ is compliant with the new 26VDC V-Lock battery standards.CONNECT+ Wi-Fi ModeSwitch your CONNECT+ to Wi-Fi mode when used with an iPad or an Android tablet. CONNECT+ is fully compatible with a multitude of Ethernet-based lighting Apps without the need for additional Wi-Fi Access point and nods.

CONNECT+ Pin CodeThe pin code lock will be used to restrict access to advanced CONNECT+ settings like Ethernet, CRMX, and so on. In addition, the HMI can be locked to avoid operator mishaps on the sets.
CONNECT+ Save & RestoreThe "Save & restore" feature enables the user to save the settings. This feature is especially useful when the CONNECT+ is hired out.CONNECT+ Recorded
The built-in DMX recorder will make it possible to record small DMX sequences from the iPAD (Wi-Fi mode). This enables you to create DMX sequences with a powerful App such as BlackOut and then play them back with the CONNECT+ or another EXALUX DMX Player.

CONNECT+ Power Over DMXIt is possible to switch PoD power on and off individually on each XLR port. This makes it possible to connect equipment that is not PoD compatible and also to power down equipment without having to disconnect them.
CONNECT+ Ethernet ModeSwitch your CONNECT+ to Ethernet mode when connected to a DMX controller with an ETHERNET cable. CONNECT+ will convert a multitude of Ethernet-based lighting protocols to physical DMX without the need for additional adapters.- TX100N Wireless DMX Transmitter -EXALUX CONNECT TX100N is an ultra compact wireless DMX transmitter that can be used in the studios or on location. CONNECT TX100N features PoD technology which enables the unit to be powered via its XLR connector. The unit is fully compliant with all Lumen Radio CRMX receivers, such as RX100S and RX200N.Cases of UseConnect the TX100N to your DMX console and turn it into a wireless DMX console allowing you to control all your CRMX compatible lighting fixtures. Connect the TX100N to your EXALUX CONNECT+ unit and manage several DMX universes wirelessly. Thanks to the PoD (PowerOverDMX), you directly power your TX100N via the XLR connector of the CONNECT+. This truly wireless!

Product BenefitsDesigned for The FieldCONNECT TX100N feature unibody enclosures milled from a block of aluminum, allowing them to get a compact and stronger design. The external antenna allows a long range, up to 500m depending on the transmitter and the environment.

Powered Over DMX
CONNECT TX100N CRMX transmitter is our first PoD-PD compliant system. PoD concept has been designed to ease powering DMX dongles (power & data in the same 5pos DMX cable). POD means less cable and a single power supply for several devices.
Wide Range Power Mode
Thanks to its wide supply range (+5 to 24VDC), CONNECT TX100N can be powered through the USB connector of a DMX fixture, a Vlock battery via the D-TAP connector or any external PSU.
Universal Mounting
CONNECT TX100N unit can be mounted on industry-standard AV/Cinema clamps, tripods and arms thanks to the 3/8 UNC adapter. It's easy, simple and it will save you time!

Removable AntennaThe connect TX100N's antenna is removable, meaning you can replace it by a different model to better suit your needs.
Lumen Radio CMRX
Based on Lumen Radio CRMX technology, EXALUX CONNECT RX200N brings DMX fidelity without any latency.
