Errebi Group - Cable Unipolar FLRY-B ISO 6722 Clase B Sec. 1,50 mmq Blanco/verde

Código ErreBi: 48433 Precio por metro:5 Nota: El artículo se vende a metros continua. Ejemplo: Si usted compra 3cantidades, recibirá una pieza única de 15MT APPLICATIONS PVC insulated flexible single core cables that is intended for use on low voltage electrical installations, systems and components of road vehicles where the heat exposure is not continuous on cable surface The FR125 F5 cables are mainly intended for the wiring everywhere a frequent thermal loading, but continuously on cable, could be occurred. CABLE STRUCTURE 1. Flexible electrolytic bare copper conductor: stranded multi-wire 2. Type B and class T2 105°C rated PVC insulation Temperature range: -40 to 105°C (fixed) Short-circuit temperature: 160°C Voltage: 220 V. c.a. 300 V. c.c. Test voltage: 3 kV AC ( 0.50 mmq) Flame resistance: DIN 72551 Part 5, 7.Z8220, Par. 3.7 Bending radius: >= 6 x D (fixed) Suitable for indoor use Suitable for fixed installation Resistance to chemical agents: DIN 72551 Part 5, ISO 6722,
