Energy Cost Meter Electricity Meter Electricity Meter Socket 230V 16A

Features: brand new high quality Made of high-quality materials for durability Displays line power. Displays and stores the total power collected. Display and save the price of the total service. Fine workmanship and good performance. Easy to handle. Product parameters: Material: ABS and electronic components Size: About 98*76*52mm Power supply: 230V-50Hz Maximum load: 16A 3680W Minimum power display: 0.1W Measurement accuracy: +/- 2% or +/- 2W (0-100W); +/- 2% (100-3250W) Performance Accuracy: +/- 2% Minimum power display: 0.01KWh Cumulative power range: 0.00-9999.9KWh Price range: 0.00-9999 Data Display: Press the MODE key the data is displayed as follows: W-KWh-Price-Cost KWH 1). Plug in a power outlet and turn on the power the meter will display active power. 2). Press and release the MODE button again and the meter will display the accumulated KWh. 3). Press and release the MODE button again and the meter will display the total power. 4). Press and release the MODE button again and the meter will display COST-KWH. Fixed price/kWh price: 1). When COST-KWH is displayed press SET key the first digit of COST-KWH flashes press UP key to set. 2). Press the SET button again to release the second digit of COST/KWH flashes press the UP button to set. 3). Press the SET button again release it when COST/KWH flashes for the third time and press the UP button to set. 4). Press the SET button again release it when the COST-KWH flashes for the fourth time and press the UP button to set. 5). Press the SET key again to release the decimal COST or KWH flashes press the UP key to set. Data erasure: Press and hold the MODE button for five seconds and the KWh PRICE and COST/KWh data will be cleared. annotation: Do not connect two or more instruments together! Do not plug in devices with loads greater than 16A. Always make sure that each device s plug is fully inserted into the meter s outlet. To clean the meter unplug it from the power adapter and wipe the meter with a dry cloth. Package Included: 1x meter socket Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data.
