EleksMaker® PWM To TTL Transition Module for Laser Engraving Machine Controller Board Mana SE IVAxis

Description This PWM TO TTL transition module is design for EleksMaker series machine and its controller board But it can also be used for other DIY machine which need to transform the modulation from PWM to TTL Specification Power Port Size 5 5 2 1mmWorking Voltage DC 12VWoring Power 2AWeight About 10gFAQsInstructions 1 When or why I need to have a PWM TO TTL transition module As known Eleksmaker controller board is designed with a 3 pin port 12V GND PWM for connection to laser module with the same port However if your laser module is designed as 2 2 54 2P port 2 2 pin port usually power port and TTL port it can not be directly used on EleksMaker series machine Therefore you need to have a PWM TO TTL transition module 2 How to use this transition module How to transform PWM to TTL You can see 3 port on the transition module They respectively are Input Port 3 Pin White Output Power Port 2 Pin Red Output TTL Port 2 Pin White ① Connect Input Port to EleksMaker Machine Controller Board Mana SE Mana IVAxis ② Connect Output Power Port to the power port on your laser module ③ Connect Output TTL Port to the TTL Port on laser module ④ Power on ManaSE board 3 How to test whether the laser module is broken You can also see a DC Port on the transition module It can be used to test whether your laser module works or not Connect the DC Port with power supply Connect Output Power Port to the power port on your laser module Plug in power press th
