EleksMaker® EleksLaser-A3 Pro 500mW Laser Engraving Machine CNC Laser Printer

How cool the laser engraver can be.(Old version, only shows effect ): How to Assemble it : What our customers do with EleksLaser: Notice: 1.The frame joint is upgraded and will be easier to assemble.(Remove corner joints and add rubber pads) You might receive the new / old version randomly.Please make sure you know it. Thank you. 2. Videos and Customers' works do not made from this machine. Thank you. Specifications: Brand EleksMaker Model EleksLaser-A3 pro 0.5W Control Board EleksMana SE Communication Port MircoUSB Laser Quick Replace Support Stepper Motor 42H34S-1304A Power Input AC100-240V Sysytem Support Win XP/7/8/10 Engrave Mode Photo, Word, Scan, outline, Pixel Laser Engraving Supported Formats jpg, bmp, svg, G-code Material Stainless Steel and Acrylic Working Voltage DC 12V Working Current DC 2.5A Laser Power 0.5W / 500mW Control Software System Candle, EleksCam, T2-Laser, Benbox, GrblController, LiteFire, Laser GRBL, etc. Engraving Accuracy 0.01mm Engraving Area 30x40cm / 11.81 x 15.75inch (maximum) Engraved object height limitatiion No Limitation Packaging Size 58x40x14cm / 22.83x15.75x5.51inch (L*W*H) Assembled Product Size 60x46x18cm / 23.62x18.11x7.09inch (L*W*H) Package Weight 4.60kg Can Engrave Wood, Plastic, Paper, Bamboo, Ox Horn, Leather, Sponge Paper, etc. Can not engrave Metal, Stone, Ceramics, Glass, Reflective or Transparent Material Certification CE, FCC, FDA(Please contact us if you need them) Function ideal for amateur laser engraving usage low-light positioning and freedom positioning functions. Features 30X38cm ultra large engraving area,gantry shape design, no engraving height limitation. Three stepper motor drive providing faster moving speed. 500mW violet laser module with heatsink, high laser engraving power and long-term available. can print any pictures easily Tips: Laser machine installation, software downloading, software setting ,operating instructions and FAQ: Click here Laser module self-checking tips link: Click here Note(Please pay attention): 1. Please wear laser goggles during usage and avoid touching the laser directly with your eyes and skin. 2. The red cord is DC12v(+),black cord is GND(-) yellow cord is signal(S). Please make sure you know the wire position and connect to the ManaSE board correctly. 3. The warranty period of laser module is one month. If you have any quality problem(Except individual situation like using the laser module more than 30 minutes per time and casue the damage ) please feel free to ask our customer service for a help. 4. If your laser module has any problem, please DO NOT dismantle it without our permission. It will destroy the laser module. 5. If you have any quality problem about the machine, please feel free to contact us. Many operative problem can be solved according to your video and problem description. Thank you in advance. Package List: 1 Set x 500mW Laser Engraving Machine(Need to be assembled by you) FAQ: 1. How to assemble the kit? The whole assemble and operating manual link is here:Click here You can also watch the video to do it:Click here 2. What software can support this machine? And what image format? Engrave Mode? Supported Software: EleksCam,T2-Laser, Benbox, GrblController, LiteFire, Laser GRBL, etc. Supported Image Format: jpg, bmp, svg, G-code Supported Engrave Mode: Photo, Word, Scan, Outline, Pixel Laser Engraving 3. What system can the EleksCAM support? PC Windows XP/7/8/10 Laptop is ok,too. 4. My laser doesn't work, what should I do? If the machine does not work, it might because: The wire connection is wrong.Please check the connection like the picture shown. Your computer could not support the software.Please use Win XP 7/8/10 to check it. Software problem.Please check whether wires are inserted rightly. And then check your data setting. The kit misses some accessories.Please compare with the instruction and tell us, we will solve it once you send us the email. Laser module/ driver board/power supply is broken.Please check which part is the main problem,and then send us a video to prove it. Or you can send us a video about your software setting,working laser and driver board. We will analyze it and give you a solution. Laser module self-checking tips link is here: Click here 5: My software shows: Not data, what should I do? There might be two reasons. You did not open Administrator privileges to run the software. Please try this. Your computer architecture is incomplete:check whether VC ++ and. Net and directX are installed, and have to turn off the virus. 6. Can I regulate the laser power or the laser power is adjustable? Our new Mana SE controller board can adjust the power. Please download our ElekesCAM software and firmware to do it.Or benbox software and benbox firmware. Please note that two firmware is not the same. Details are shown in the EleksCAM & Benbox software instruction above. 7. Can I upgrade stronger power laser module by myself? Can I extent rail frame? Yes,you can.DC12V laser module can be installled on this machine. The red is positive.You can also extent the frame by yourself, but we do not provide rails. Please note that. 8. When I click arrows to control the motors, it works. But when I begin to make it work with EleksCAM software, it does not move. What should I do? The EleksCAM could move by hand but could not move when focus.The probelm is the area and language inside the system control panel. Please set the format to English and United States.Then it will be ok. Detail is shown in the wiki link above. 9. My laser module is always on and could not turn off.What should I do? Please try to connect the Signal(S) and GND(-). If the laser module turn off, that means the laser module is ok, the problem might be the ManaSE board or software setting. If the laser module is still on, that means the laser module might be damaged. You can check as the video shown: Click here 10. If my laser is broken and I might find the reason(Or I could not find) . What should I do? Find the reason: Take a video to prove the part is broken and then send it to us. we will give you a solution according to your video. Could not find the reason : Check the Question 4 first. If the problem could not be solved, please feel free to contact our customer service with a video: [email protected]. The video should contain software setting, broken part details and the power-on machine. We will solve it asap.
