Electronic Load Battery Capacity Tester With Temperature Display Industrial Supplies For DIY Users Mechanical

Electronic Load Battery Capacity Tester with Temperature Display Industrial Supplies for DIY Users Mechanical Specification: Description: This is an electronic load board of very high cost performance adopting two completely independent 18 bit ADC chip 15 PPM voltage benchmark which allows a high accuracy. It is better than other electronic load with single chip built-in AD sampling digital tube display or battery capacity tester. Supporting user second correction of parameters it is a best choice for DIY users. Features: 1602 LCD screen display information comprehensively. Configuration of 9cm CPU fan very quiet. With temperature display supporting the discharge and voltage setting. Test all kinds of power load or burn-in can also test capacity of battery discharge. Load maximum power 150W maximum voltage 60V maximum current 10A. Specifications: Voltage: DC 12V±5% Load Type: Constant current Load Voltage: 0.5-60V Load Current: 0-10A Maximum Power: 150W Voltage Reading : ±0.1%+0.05%FS Current Reading : ±0.2%+0.1%FS Constant Current Accuracy: Current reading + 1d Noise: 25dDA Weight: 341gapprox. Instruction: Wiring Diagram of 2 Wires Safe and convenient: Note: 2 wires must be respectively connected to A+ and A-. V+ is connected to A+ and V- is connected to A-. Wiring Diagram of 4 Wires: Note: 4 wires must be connected completely before use. 4 wires can offset voltage drop caused by electric wires under large current and ensures a more accurate voltage measurement. It is recommended if you are a professional. 4 wires must be all connected correctly before you power on the load. Wrong wiring is likely to cause damage please make sure the wiring is correct! As you can see in the picture there are thick wires and thin wires. The thick wires are for current the thin wires are for measuring voltage and of course you can use thick wires for all. Below is the operation interface. The operation is very simple and easywhen it displays ON it must be connected to load otherwise it will beep and won t work Bottom left screen corner will display information that automatic switching between power AH temperature time and can be set to always display certain one. I : Setting load current V : Setting discharge cut-off voltage. 1 the power adapter: DC 12V load power and power supply should be 2 independent power. 2 Power on and screen shows Welcome to use which means equipment is normal 3 Press set to move the cursor add and subtract operations according to the cursor position. When the cursor position is at I or V press add or subtract button to switch current and voltage setting. 4 Connect to power source that need to be tested and make sure the wiring is correct. 5 Press start button to start/stop electronic load and screen shows ON or OF 6 Press and hold start button for more than 1 second to reset AH and time and power off the electronic load if it was powered on 7 The bottom left screen corner will display information that automatic switching by default every 2 seconds between power AH temperature time. Press and hold set button then press add button to switch and the display information will not switch
