Electromagnetic Gun DIY Kit Electromagnetic Experiment Equipment

Description The internal working voltage of this device can reach 90 100V which exceeds the international safety voltage standard of 36V Therefore when it is powered on and working do not touch the internal electronic components otherwise electric shock accidents will occur The insulation skin of external electronic components such as coils is thin so it is necessary to avoid damage and leakage caused by rubbing The switch is also a weak link If it is exposed the risk will be higher in the version without a casing so pay attention to handling Self assembled circuit boards inevitably have errors or faults If the booster circuit is already working normally the voltage of the energy storage capacitor 1000UF 100V may have been charged to a higher value causing electric shock hazards Therefore before troubleshooting and processing first use a multimeter to measure the voltage at the two legs of the energy storage capacitor or directly use a plastic skinned wire both ends are stripped to expose the copper wire pinch the plastic skin and use both ends of the copper wire Touch the two feet of the capacitor to discharge After the charge is completely released the capacitor voltage will drop to OV and then it can be safely operated with bare hands Specifications Product name primary electromagnetic gunPCB board size 52 50MM 82 80MMCircuit board material FR 4 board 1 6MMPackage Include 1 Electromagnetic Gun DIY Kit Not included shell
