Electro-Voice Sx300PIX 300W 12" 2-Way Weather-Resistant Loudspeaker,Single,Black

The Electro-Voice SX300PIX 300W 12" 2-Way 65 x 65 Full-Range Weather-Resistant Black Loudspeaker is a continuation of the popular the SX-series offering the added value of weather-resistant cabinets. This is a 300-watt, 12-inch, two-way, high-efficiency, constant-directivity speaker system for permanent installation. Through the extensive use of computer-aided design and modeling, Electro-Voice engineers have developed a state-of-the-art professional loudspeaker system for permanent installation where weather resistance is needed with the addition of an AT100 transformer. It's high-frequency section utilizes a molded-in, 65deg. X 65deg. constant-directivity horn. This unique pattern contributes to high intelligibility. Vocals sound natural, yet "cut through" in reverberant, noisy rooms. In addition, the coverage pattern is unusually uniform over its range of operation. Sound quality off axis is very consistent, even at 45deg. off axis (a 90deg. total coverage angle), well beyond the rated coverage angle. The horn's unique, Varipath throat geometry helps direct driver output to the corners of the room, points of coverage not described in the usual specifications of horizontal and vertical coverage angles and parts of the audience that typically do not receive the strongest coverage. Constructed of high impact polypropylene structural foam, it provides a stiff and extremely durable enclosure. Molded into the cabinet are an integral carrying handle and a stand socket for mounting on 13/8" stands such as the Electro-Voice 100BK. Rubber feet attached to the bottom of the cabinet and mating sockets molded into the top provide a means of stacking systems.The trapezoidal-shaped cabinet in combination with the uniform, 65deg. X 65deg. directivity characteristics, make the loudspeaker ideal for use alone or in arrays. The DH2010A uses a unique, convex-drive Time Path phasing plug structure for smooth and extended high-frequency performance. The voice coil is coupled to the diaphragm with EV's exclusive Resonant Drive technology. This increases and smoothes the high-frequency response and reduces the amount of internal equalization required for flat frequency response. Driver output extends to 25,000 Hz. A self-resetting, high-frequency protection circuit, EV's PRO circuit, is to prevent accidental overdrive and improve system reliability. If the input power to the high-frequency driver exceeds the nominal rating, the protection circuit is activated and reduces the power delivered to the driver by 6 dB. The system will remain in this mode of operation until the input power is reduced to a safe level. The bass section of this loudspeaker is designed using Thiele-Small parameters for efficient performance to below 80 Hz. The woofer is a DL12SX 12-inch unit featuring beryllium copper lead wires, a low-mass, edge-wound voice coil and high-temperature materials. The part of the magnetic structure adjacent to the coil is insulated using the exclusive EV PROTEF process. The system combines professional-quality components, arranged in a time-coherent vertical array, with an unusually durable Thiele-Small aligned vented enclosure. The result is clear and articulate, high-quality sound.
