Electro-Harmonix Crash Pad Analog Drum Synth Pedal

Reissue of the original drum synthesizer pedal!
EHX's rich history was marked by many revolutionary pedals but one of our most distinctive lines was a group of analog drum synthesizers that included the Crash Pad.
Like the original from 1980, the EHX Crash Pad Electric Crash Drum can create an array of drum sounds and other-worldly oscillation sweeps, as well as process external sounds thru its resonant filter. Plus, it's been updated to respond to expression pedal/CV input for external control over the filter in real-time.

Sens. ButtonControls the sensitivity of the Crash Pad to an external trigger. Sensitivity is high in the down position and low in the up position.
Start KnobSets the starting point of the frequency sweep.

Stop Knob
Sets the end point of the filter's frequency sweep.

Time KnobControls how long it takes to sweep from the START frequency to the STOP frequency.
Resonance Knob
Adjusts the resonance (or Q) of the low pass filter.Volume KnobControls the volume of the output signal.
Decay KnobEach time the Crash Pad is triggered, an internal volume envelope is activated. The DECAY knob sets the time it takes for the volume envelope to fade out the triggered sound.

Push Button Trigger
The white button at the center of the logo. This push button triggers the Crash Pad. Push this button to create amazing sounds.Output Jack
This 1/4" jack is the audio output from the Crash Pad.
Ext. Trig JackThis 1/4" jack is the input for an external trigger.
Aux in Jack
This 1/4" jack is the auxiliary input for an external sound source.

Exp. Ped Jack
Connect an expression pedal with a TRS plug to this jack to control the filter sweep with your foot.
