EaglePower SA2205 2205 2300KV 2600KV 3-4S Brushless Motor for RC Drone FPV Racing

EaglePower SA2205 2205 2300KV 2600KV 3-4S Brushless Motor for RC Drone FPV Racing Specification: Brand Name: EaglePower Model: SA2205 Item Name: 2205 2300KV 2600KV 3-4S Brushless Motor KV: 2300KV / 2600KV (Optional) Screw Thread: CW Screw Thread Input Voltage: 3-4S Lipo Shaft Diameter: M5 Motor Width: 28.2mm Motor Height: 29mm Weight: 28g No-Load Current: 0.8A @12V Max. Con. Current:20A (2300KV) / 24A (2600KV) Max. Con. Power: 255W (2300KV) / 295W (2600KV) Internal Resistance: 0.1(2300KV) ; 0.07 (2600KV) Recommend Propeller: 5040 / 5045 Prop Testing Table: Motor Type Lipo Battery Propeller Current (A) Pulling Force (g) Power (W) Efficiency (g/W) Temperature () 2300KV 3S 5045 2 140 22.2 6.3063 4 230 44.4 5.1802 6 320 66.6 4.8048 8 370 88.8 4.1667 42 5 Min. 10 430 111 3.8739 46 5 Min. 12 500 133.2 3.7538 14 580 155.4 3.7323 4S 5040 2 160 29.6 5.4054 4 260 59.2 4.3919 8 450 118.4 3.8007 10 550 148 3.7162 46 5Min. 14 720 207.2 3.4749 52 5Min. 16 780 236.8 3.2939 21 950 310.8 3.0566 Motor Type Lipo Battery Propeller Current (A) Pulling Force (g) Power (W) Efficiency (g/W) Temperature () 2600KV 3S 5045 3 192 33.3 5.7658 6 295 66.6 4.4294 9 385 99.9 3.8539 12 450 133.2 3.3784 46 5Min. 15 510 166.5 3.0631 50 5 Min. 18 580 199.8 2.9029 20 630 222 2.8378 6040 4 255 44.4 5.7432 8 380 88.8 4.2793 12 490 133.2 3.6787 16 560 177.6 3.1532 50 5 Min. 20 630 222 2.8378 55 5 Min. 24 710 266.4 2.6652 28 780 310.8 2.5097 Package Included: 1x EaglePower SA2205 Motor
