Eachine TX805 5.8G 40CH 25/200/600/800mW FPV Transmitter TX LED Display Support OSD/Pitmode/Smart Audio

Specification: Brand name: Eachine Model: TX805 Item name: FPV Transmitter VTX Frequency: 5.8G Channels: 40CH Input voltage: 7V~24V 5V camera supply: 120mA(MAX)----25mW@12V 5V camera supply: 200mA(MAX)----200mW@12V 5V camera supply: 300mA(MAX)----600mW@12V 5V camera supply: 350mA(MAX)----800mW@12V Extra features: Smart audio Power supply: 5V output for Camera Output power: 25mW/200mW/600mW/800mW switchable Antenna connector: MMCX Cable connector: Solder pads Dimensions: 36mm*22mm*5mm,30.5 stackable hole Weight: 8g(excluding antenna) Features: 1. Pitmode 2. Support Smart audio 3. 40 channels with MIC 4. Power failure memory 5. 25/200/600/800mw power switchable 6. Support OSD Configuring via Betaflight FC 7. One button frequency and power setup 8. 7-24V wide input voltage with 5V for camera,12V typical corresponding current value: 25mw-120mA 200mw-200mA 600mw-300mA 800mw-350mA 9. Solid MMCX antenna connection and MMCX brass dipole antenna Button control Channel select mode Channel select Select channels by simple short presses. Blue LED light on stands for CH1,short presses to change 8 channels sequentially. For CH2/3/4/5/6/7/8,Blue LED flicker once,it won't light on. Notice:Blue LED only light on for CH1 Band select Press button for 2S,Red LED will flash,then short presses to select 5 bands. Power select Press button for 4S,Red LED will flash,then select power by simple short presses to select 25mW/200mW/600mW sequentially,For 200mW, Green LED flicker once,it won't light on;For 600mW Blue LED flicker once,it won't light on .Press the button again ,Red LED,Green LED and Blue LED lights together,Represents the highest power 800mW. Notice:Red LED only light on for 25mW. Pit Mode(0.01mW) While in Pit Mode you can change channels and set power levels but none of these changes will take effect until you quit Pit Mode.By default ,Pit Mode will send a very weak signal. Two ways to exit pit mode: Press button 12S until all 16 LED turned off and light on again to exit pit mode,or you can exit pit mode via Betaflight OSD. Notice:The VTX has memory for settings,To change the settings ,please repeat steps as above. Package included: 1 x Eachine TX805 5.8G 40CH 25/200/600/800mW FPV Transmitter VTX 1 x Adapter connector cable (RP-SMA or SMA Female) 1 x MMCX Pigtail Antenna 1 x Instructions
