Eachine NANO VTX 5.8GHz 48CH FPV Transmitter With Runcam Racer Nano CMOS 700TVL 1.8mm FPV Camera Combo for FPV Racer Drone

Description: Item Name: Eachine NANO VTX + Runcam Racer Nano 1.8mm Camera Specification of Runcam Racer Nano: Brand name: Runcam Model: Racer Nano Image Sensor: Super WDR CMOS Sensor Horizontal Resolution: 700TVL Lens: 1.8mm (M8) FOV160 Screen Format: 4:3 / 16:9 Switchable Signal System: NTSC / PAL Switchable Mirror System: Available Integrated OSD: Yes One touch Scene Setting: Personal / Lightrax / Darkness S/N Ratio: >50dB Electronic Shutter Speed: Auto Min. illumination: [email protected] WDR: Super WDR Day/Night: Color Menu Control: Gesture Control / Joystick Control Power: DC 3.3-5.5V Working Current: 120mA@5V / [email protected] Housing Material: ABS Net Weight: 3.5g Dimensions: L14mm*W14mm*H16mm Specification of Eachine Nano VTX: Brand Name: Eachine Item Name: NANO VTX Output Power: PIT/25mW/100mW/200mW/400mW Switchable Control Mode: BFOSD Control(RX)/Button BAT: 5V Video System: NTSC/PAL Antenna: IPEX Size: 14MM*15MM*4MM Weight: 1.5g Features: - 5.8GHz 48CH FPV transmitter - 5V input voltage - 25/100/200/400mW power switchable - Support OSD configuring via Betaflight flight controller Frequency Table(Mhz): FR/CH CH1 () CH2() CH3() CH4() CH5() CH6() CH7() CH8() Frequency A() 5865 5845 5825 5805 5785 5765 5745 5725 Frequency b() 5733 5752 5771 5790 5809 5828 5847 5866 Frequency E() 5705 5685 5665 5645 5885 5905 5925 5945 Frequency F() 5740 5760 5780 5800 5820 5840 5860 5880 Frequency r() 5658 5695 5732 5769 5806 5843 5880 5917 Frequency L() 5362 5399 5436 5473 5510 5547 5584 5621 English Manual of Eachine Nano VTX, Click Here English Manual of RunCam Racer Nano camera, Click Here Package Included: 1x Eachine NANO VTX 5.8GHz 48CH 25/100/200/400mW Switchable FPV Transmitter 1x RunCam Racer Nano camera 1.8mm 1x 1419 TPU bracket 1x Set of screws 1x IPEX Antenna 1x User Manual
