[EU Direct]BIGTREETECH BTT SKR 3 EZ 32Bit Motherboard EZ5160 Pro TMC2208 Upgrade SKR2 Control Board For Raspberry Pi End

BIGTREETECH SKR 3 EZ V1 0 motherboard is a 32 bit 3D printer motherboard updated by the team of Shenzhen Biqu Technology Co Ltd for our EZ series drivers on the basis of SKR 3 It is compatible with boththe EZ series driver and the series of TMC drivers Download firmware URL https biqu3d com pages downloadFeatures1 Using 32 bit ARM Cortex M7 series STM32H743VIT6 STM32H723VGT6 main control chip the performance has greatly improved 2 The power chip adopts TPS5450 5A which supports DC12 24V power input The output current of the chip is up to 5A and the peak value can reach 6A which perfectly supports the power supply of Raspberry Pi 3 The motherboard reserves the BOOT button users can update the motherboard boot program through DFU 4 Increase the protection circuit of the thermistor part to avoid the burning of the main control chip due to leakage of the heated bed or heating rod 5 The numerical control fan realizes 24V 12V 5V voltage selection through the external power supply module eliminating the need for the operation of the customer s external transformer module thereby reducing the probability of damage to the motherboard 6 The thermistor can select the pull up resistance value through the jumper and support PT1000 in this way without the need for external modules which is convenient for customers to use DIY 7 Support all versions of our company s serial screen SPI screen and LCD screen 8 Upgrade the configuration firmware through an SD card the
