ETX-1825 Multi-function Process Calibrator Multimeter with A Split-screen Display Support for PC Communication

Features A split screen display The upper display allows you to measure volts current with loop power resistance and continuity test The lower display allows you to measure and source volts current resistance temperature detectors RTD thermocouples TC frequency and ohms Calibrates a transmitter using the split screen The measure of thermocouple provides automatic reference junction Automatic and manual cold end temperature compensation for TC Manual stepping and automatic stepping and ramping Super strong protection The waterproof grade is IP67 Automatic protection against the signal terminals connect to the 220V Support for PC communication Accuracy 0 05 Specification FunctionMeasureSourceDC V0 50V the upper display30V 0 10VDC mA0 24mA the upper display24mA 0 24mAFrequency1 000Hz 100 00kHz0 00Hz 20 000kHzResistance0 32000 3200DC mV0 100mV the upper display200mV 0 100mVRTDPt100 Pt1000 Cu50 Cu100Pt100 Pt1000 Cu50 Cu100TCE J K T B R S NE J K T B R S NOthersLoop supply Step Ramp Dual displayPlease Click Here to Download the English User Manual Package included 1 x ETX 1825 Multi function Process Calibrator Details pictures
