ET44 Series Desktop Digital LCR Meter Capacitance Resistance Impedance Inductance Measure LCR Bridge LCR Meter

Please click here to download the softwarePlease Click Here to Download the English User ManualPlease click here to download the softwareDescriptions ET44 series desktop bridge incorporates 3 5 inch TFT display user friendly interface and a variety of measurement parameters into one body It is convenient for users to carry out remote control with USB and RS232 and also perform the sorting of components using handle In function it can not only adjust the output frequency and test level but also record the value of components in the process of measurement In the performance parameters its basic accuracy reaches 0 2 Features ● Measurement frequency up to 100kHz● Test level 100 2000mV●Support the measurement of DC resistance and electrolytic capacitor●Internal bias voltage output 1mV 1500mV ●Automatic identification of component measurement●3 5 inch TFT display 5 and a half bits display●USB RS232 communication interface Handle sorting● Data recording function maximum and minimum values average value ● Support SCPI communication protocol● Provide system settings which can configure language buzzer screen brightness etc according to the needs of users ● Basic accuracy 0 2 ● Manual and automatic range● Be equipped with open circuit and short circuit correction● Comparator has sorting and alarm function● Provide a variety of test portsSpecifications ModelET4401ET4402ET4410DigitsMain parameter 5 digits secondary parameter 5 digitsMeasurement ParameterMain para
