ESCAM K508 Mini NVR Network Video Recorder IP Camera

Highlights of ESCAM K508 Mini NVR IP Camera
Support Onvif Protocol.
Support 18S super Protocol.
Build in 1 SATA Interface and support 2.5 inch HDD.
Support P2P cloud service, remote viewing.
Support megapixel HD network video preview, storage and playback.
Support search, playback and backup by event.
Offer CMS for free.
Specifications
Brand ESCAM
Model MINI NVR K508
Operating System Embedded LINUX operating system
Image Code Control Image code quality adjustable, variable bitstream and constant bitstream optional
Dual Stream Each channel can set main stream and sub stream
Video Resolution 1080P (1920×1080) 30fps, 960P (1280×960), 720P (1280×720) 30fps
Image Motion Detection Each screen can set multiple detection areas and set 6-level sensitivity
Recording Playback Quality 1/4/8ch playback simultaneously
Region Cover Every channel can set 4 cover regions (IPC Support)
Recording Mode Support manual, auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support)
Backup Way Support U disk, USB mobile HDD, USB DVD-RW. network storage and backup
Operation Way Mouse
Local Login Username and password
Recording Storage Local HDD, network
Video Input 8×(1280 x 720)+sub[640*360]+1Ref.+4Play 8CH 1.0MP IP Camera
8 x (1280 x 960)+sub[640 x 480]+4Ref.+1Play 8CH 1.3MP IP Camera
8 x (1280 x 1080)+sub[640 x 480]+2Ref.+1Play 8CH 2.0MP IP Camera
8 x (1920 x 1080)+sub[720 x 576]+1Ref.+1Play 8CH 2.0MP IP Camera
Audio Input 8ch network audio input
Video Output 1ch VGA+1ch HDMI
Network Port 1 RJ45,10M/100M self-adaptive LAN port
USB Port 2 USB 2.0 ports
HDD Port 1 2.5” SATA HDD Port + 1 E-SATA HDD Port
HDD MAX. Capacity Each port supports MAX 4TB HDD
Mobile Access iOS, Android
Power Supply 5V2A
Work environment -10 - 60 Celsius degrees
Product Dimension 162 x 162 x 35 mm
Product Weight 280g
