ER16 Clamping 1~9.5mm Spring Collet for CNC Milling Lathe Tool Engraving Machine

Features: * Brand new and high quality * Made of high quality materials sturdy and * Large clamping force wide clamping range and high precision. * and stable performance. * Special angle groove increases rigidity * The overall balance of the tool handle assembly is better * Use with any standard ER collet for cool tool applications. * Widely used in milling boring drilling tapping CNC engraving spindle machines etc. Specification: Size (optional): ER16-1.5mm ER16-1/4 ER16-1/8 ER16-10mm ER16-1mm ER16-2.5mm ER16-2mm ER16-3.5mm ER16-3mm ER16 -4.5mm ER16-4mm ER16-5mm ER16-6mm ER16-7mm ER16-8mm ER16-9.5mm ER16-9mm Material: carbon steel Accuracy: 0.015mm Hardness: HRC40 Taper: 16 degrees Clamping range: 1~9.5mm Overall height: 27.5mm Diameter: 17mm Package Included: 1 x spring collet Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data.
