EOTVIA Outlet Connector Consumer Electronics M8-B-S6 Pass Socket 6Pin M8 Connector IP67 Front Board Mounted Epoxy Resin Sealing

Feature: 1. Brass nickel‑plated shell connector is with excellent 360° full shielding function and damping design. 2. The connector is in line with IEC 61076‑2‑101 Industry 4.0 protocol and NEMA2000 standard. 3. Waterproof grade IP67 not afraid of harsh rainy weather you can use it more at ease. 4. Rated current is 4A rated voltage is AC/DC250V and conductor specifications is AWG22 0.34mm². 5. Exquisite production with good performance and higher working efficiency brings you more convenience. Specification: Item Type: Socket Connector Shell Material: Brass Nickel Plated Sealing Material: Epoxy Resin Pin Material: Brass Gold-Plated Rubber Core Material: PA66 Molding Material: TPU/PVC Rated Current: 4A Rated Voltage: AC/DC250V Conductor Specifications: AWG22 0.34mm² Contact Impedance: ≤5mΩ Insertion Times: ≥500 Times Number of Cores: 6 Standard: IEC61076-2-101 Applicable Temperature: -25℃ to +80℃ Waterproof Rating: IP67 Package List: 1 xSocket Connector
