EDUP EP-AB003 2.4Ghz 5W 802.11n Wireless Wifi Signal Booster Repeater Broadband Amplifiers for Wireless Router

Features
IEEE 802.11b/g/n compatible.
Signal activity LED indicates.
High Gain, High Value, High Performance.
Maximum output power of 8000mW by the Booster.
Easy installation, plug and play, no driver needed.
Ideal for increase the 2400-2500Mhz frequency devices.
Increase the effective range and coverage area of your Wi-Fi network.
Works with most of wireless access points/routers.
The amplified wireless signal may even penetrate complex environments with many walls and obstacles.
Ideal for using with detachable 2.4GHz Antenna equipments.
Note
The item need connect with the Access Point Router together, then it can work and the Access Point Router is NOT included.
How to connect
Step 1: Remove the antenna from the wireless router(access point).
Step 2: Use RG316 cable to connect the booster and AP.
Step 3: Connect the antenna to the other end of booster.
Step 4: Plug in the power adapter.
Specifications
Support Standards IEEE 802.11b/g/n
Operation Range 2400-2500 MHz.
Working Pattern TDD
RF Output Power 39dBm(5W)
Input Power 3dBm (Min.)-20dBm (Max.)
Transmit Gain 17dB typical
Receiver Gain 11dB typical
Switch Time Delay>1us
Noise Figure 30dB(typical)
Operating Temp -40-70degree
Working Voltage 6-18VDC
Operating Humidity up to 95 rel. humidity
Material Cast Aluminum.
Product Measurement10cm x 10cm x 2cm
Product Package Measurement 20.5cm x 6.5cm x 16cm
Plug Type US/UK/AU/EU
Weight 720g
What's in the box?
1 x Wifi repeater
1 x Antenna
1 x Power adpter
