EBTOOLS Logarithmic Detector Module AD606 RF Signal Log Power Meter LowPower Consumption
Feature: 1. 50MHz 80dB demodulation logarithmic register with AD606 output limiter module 2. Adjustable output amplitude used for wide range and signal power measurement 3. The product possess 65mW CMOS-compliant power saving mode with 325μW (typical value) 4. 80dB demodulation logarithmic come with low power consumption very practical 5. The product with stable structure excellent performance stable and durable for a long service life Specification: Item Type: Logarithmic Detector Log Performance: Dynamic Range: -75dBm to +5dBm Input Noise: 5nV≤1 Hz-Operating Frequency: > 50 MHz Output Voltage: 37 5mV dB-on-chip step-low output filter Performance Limiter: Plane Output: ±1dB (at 80dB) Phase Stability: ±3° (80dB within 10.7MHz) Adjustable output amplitude Low Power Consumption: Separate Power Supply: + 5V- Typical Power Consumption: 65mW-CMOS-Compliant Power Saving Mode: 325μW (typical value) On/Off:
