E6013 - General Purpose / Mild Steel - Welding Electrode - 14 x 1/8 (11 LB)

E6013 - GENERAL PURPOSE - MILD STEEL STICK ELECTRODE AWS A5.1 Welding Positions: All AC & DC± (reverse or straight polarity) INTRODUCTION: Rutile/cellulose coated stick electrode. Can be welded in any position including vertically down. Excellent ignition and re-ignition characteristics. Even with rusty primed and galvanized workpieces thanks to the aggressive arc. Very good mechanical quality values APPLICATIONS: Sheet metal. Irregular short welds that change positions. Maintenance or repair welding WELDING PARAMETERS: Polarity Current (Amps) 3/32” (2.4 mm) 1/8” (3.2 mm) 5/32” (4.0 mm) 3/16 in (4.8 mm) AC 75-105 110-140 160-200 205-260 DC± 70-95 100-135 145-180 190-235 CHEMICAL COMPOSITION (%): Chemical Composition C Mn Si S P Requirement ?0.20 ?1.20 ?1.00 ?0.035 ?0.040 Typical test result 0.079 0.38 0.21 0.018 0.024 Chemical Composition Ni Cr Mo V Requirement ?0.30 ?0.20 ?0.30 ?0.08 Typical test result 0.020 0.032 0.005 0.010 MECHANICAL PROPERTIES OF DEPOSITED METAL: Test Item Rm (N/mm2) Rel (N/mm2) A (%) KV2(J) 0? Requirement ?430 ?330 ?16 ?47 Typical test result 485 380 28.5 86 The above parameters are for reference purpose.
