Dual-axis XY Joystick Sensor Module PS2 Joystick Control Lever Sensor KY-02

Description Two axis key joystick sensor module by the use of PS2 rocker potentiometer with X Y 2 axis analog output Z 1 button digital output With the ARDUIN0 sensor expansion board can produce remote control and other interactive works In addition this product in order to allow customers to more easily with the ARDUIN0 expansion board and other standard interfaces in the design of the X Y Z axis of the circuit are separate leads the user can use 3 pin ARDUIN0 special line really plug into the expansion board Product performance 1 Input voltage range DC 3 3V to 5V2 Output signal the module special two way analog output and a digital output interface the output value corresponding to X Y biaxial offset the type of analog keys that the user press the Z axis Its type is digital switch 3 ARDUIN0 controller can be programmed the sensor expansion board plug complete with creative remote interactive works 4 Cross joystick is a bi directional 10K resistor with the rocker in different directions the tap resistance with the change This module uses 5V power supply the original state of X Y read voltage of 2 5V or so when pressed with the arrow direction the read voltage value increases with the maximum to 5V arrow in the opposite direction to press read the voltage decreases The minimum is 0V Tutorial In the introduction of how to use we first look at how it works which we use it very helpful there is a function of the following diagram
