Dual Serial Port Ethernet Bidirectional Transparent Transmission RS232/485 to Network Module RJ45 RS232/485 TO ETH

Documents USER MANUALCodeSoftwareFeatures Using M4 series 32 bit ARM processor the main frequency is up to 120MHz the running speed is fast stable and reliableSupport 10 100M Ethernet interface support Auto MDI MDIX Cross connect direct network cable arbitrary connection automatic switching Support RS232 and RS485 interfaces the two interfaces can work independently at the same time without affecting each otherSupport to set the communication baud rate 600bps 230 4Kbps support None Odd Even Mark and Space five kinds of verificationOnboard multiple function indicator lights convenient to check the module communication and running statusWorking mode optional TCP Server TCP Client UDP Server UDP Client HTTPD Client support GET and POST Support Modbus gateway function more convenient for industrial useSupport Websocket function can realize two way transparent transmission with RS232 RS485 port directly through webpageSupport web page AT command serial port protocol and network protocol setting parameters provide setting protocol customers can integrate into their own softwareSupport custom heartbeat packet mechanism to ensure the connection is true and reliable and can also be used to actively capture sensor dataSupport custom registration package mechanism automatically send a predetermined registration package as a logo after establishing a connection which is convenient to distinguish different devicesSupport custom web page function convenient f
