Dual 12 Position 15A 600V Screw Terminal Strip Covered Barrier Block

Description: Dual 12 Position Screw Terminal Strip Covered Barrier Block 15A 600V Specification: Model TB-1512L Pitch 7.5mm Poles 12P (Dual Row) Material: Screw: M4, Steel, Ni plated Terminal: Brass or Tin plated Contact: copper Housing : polyphenyl or polycarbonate Certification CE, CCC, UL, ROHS Wide/High/Thick 128.5mm / 22mm / 17.5mm Capability: Rated voltage: 600V Rated current: 15A Wire section:0.5-1.5 Withstanding voltage: AC2000V/ 1Min Temperature: -40~+105 Wiring Method: Barrier Terminal Applications: Integrated Circuits IC Interface Type: AC / DC Feature: TB series Barrier Terminal Block, 12 position, double row. The terminals are insulated from each other. Lead numbers were marked on the plastic cover. One mounting hole at each end. Good to build prototype project, electric wiring, other electronic design for electricians or technicians. Package included: 1x TB-1512 Screw Terminal Type Rated Data Number of Poles Dimensions(mm) TB-1512L 15A 600A 12 L L1 A B C D E 128.5 108 7.5 9 M3 10.5 22
