Drillpro 13pcs ER11 1-7mm Spring Collet Chuck Set for CNC Engraving Milling Mahchine Lathe Tools

Description Drillpro 13pcs ER11 1 7mm Spring Collet Chuck Set for CNC Engraving Milling Mahchine Lathe ToolsSpecification Type Machine Tool AccessoriesBrand Collet chuckApplicable machine CNC machineAccuracy 0 015mmHardness 45 48Taper Standard taperMaterial HSSModel ER11 13pcs 1mm 7mm 1mm 1 5mm 2mm 2 5mm 3mm 3 5mm 4mm 4 5mm 5mm 5 5mm 6mm 6 5mm 7mm The correct method of mounting the collet nut 1 Put the chuck into the pressure cap gently turn the clamp spring when eccentric portion of the pressure cap recessed clamp spring groove Along the arrow direction and use equal force to push clamp spring can mount pressure cap 2 Put the clamp spring and cap all together installed on the chuck body or spindle Insert into the clamping hole after wipe the cylindrical shank use a wrench to tighten the pressure cap until clip firmly the tool before use Note Avoid fastening pressure cap that not installed tool to avoid damage the clamp spring 3 Use a wrench to loosen the pressure cap and took out the chuck or tool remove the tool Along the direction of the arrow push out the clamp spring Then according to need replace other clamp spring Package Included 13 x ER11 Spring ColletMore Details
