Domqga Motion Control Card Motion Control Card Green CNC Machine Board With Relay 200KHZ Pulse Output CNC Machine Board

Feature: 1. Up to 200KHZ pulse output per shaft. (When 3-shaft linkage it can output 200KHZ 4-shaft 140KHZ and 5-shaft 100KHZ simultaneously. 2. Provide 14 output port (5V level) which can be flexibly configured as pulse and direction output of 5-shaft and can also be configured as different output or enable functions. 3. Support various versions of software support latest version 4. Support Windows XP WIN7 WIN8 WIN10 64-bit systems laptops tablets 5. All input signals are optically isolated which can be connected to emergency stop tool setting limit return to 0 etc. to ensure computer safety 6. One 0-10V analog voltage output isolated by optocoupler which can control the inverter with 0-10V analog voltage input and control the spindle speed 7. Provide PWM output (5V level) can be connected to the spindle speed controller controlled by PWM 8. Output port (5V level) can be connected with relay module with solid-state coupling solid state relay control water cooling spray etc. 9. Can be connected to common anode or common cathode input level is 5V stepper motor driver or servo motor driver with optocoupler input (pulse + direction) 10. A 5-shaft interface cable socket (XH2.54) is also provided. 11. Provide electronic handwheel interface and can be expanded to 10 inputs 12. Print all port names you can easily to distinguish 13. Carefully crafted to ensure stable operation Specification: Item Type: Motion Control Card + Relay Peripheral Wide Voltage Input: 13-24V (with anti-reverse function) Package List: 1 x Control Card 1 x Relay 2 x Connecting Cable
