Domqga Control Mechanical Equipment Safety Light Curtain Safety Light Curtain Photoelectric Protection Sensor PNP NO Output Control Device DC10‑30V

Feature: 1. Using mature infrared scanning technology excellent optical performance and 2.5° divergence angle easy to align and maintain. 2. The safety light curtain sensor complies with the International Electrotechnical Safety Society IEC61496‑1/2 standard. 3. The shell is made of aluminum alloy which is light and wear‑resistant and is not easy to corrode after long‑term use. 4. Slotted slide rail design and made of cold‑rolled steel plate with glossy exterior is easy to install. 5. Widely used in the individual and object safety protection of the mechanical processing industry and the safety of mechanical equipment. Specification: Item Type: Safety Light Curtain Material: Aluminum alloy Model: TOSD04D-40-PK Detection Distance: Approx. 0.3-3meter / 1-9.8ft Operating Voltage: DC10-30V Rated Current: 200mA Optical Axes Number: 4 Optical Axes Spacing: Approx. 4cm / 1.6in Output Mode: PNP normally open Response Time: ≤30ms Anti-light Interference: Ambient Light: Maximum 10000Lx Incandescent Lamp: 3000Lx Ambient Temperature: Working: -10-+55℃ (under non-icing state) Storage: -30-+80℃ (under non-icing state) Uses: Widely used in the mechanical processing industry and the safety of machinery and equipment the individual safety of operators and the safety of objects. Package List: 2 x Sensors 1 x 3-Core Cable 1 x 4-Core Cable 4 x Brackets 4 x Screws 4 x Metal Gaskets 1 x User Manual Note: Please do not pull out the plug‑in unit or wiring when the power is on. If you operate in violation of the regulations the internal stand‑alone chip will be damaged and cannot be repaired.
