Docooler Signal Frequency Generator OLED Display Phase-Locked Loop Module Sensors Excitation Source Line Loss Attenuation Detection Module

Please note this item ships from an international seller. Expected delivery is 10-15 days. Phase-locked loop module with OLED display USB communication port for upper computer integrated button operation wide voltage power supply nice human-machine interaction interface etc. The module can reach 23.5MHz-6GHz frequency output point frequency frequency sweeping frequency hopping and other basic functions. Features: The MAX2870-OLED is used in conjunction with an external loop filter and external reference frequency to implement an integer N frequency-locked loop (PLL) frequency synthesizer. Phase-locked loop module with OLED display USB communication port for upper computer integrated button operation wide voltage power supply nice human-machine interaction interface etc. The MAX2870 features an integrated voltage-controlled oscillator (VCO) with a basic output frequency ranges of 3000 MHz to 6000 MHz. In addition a 1/2/4/8/16/32/64 crossover circuit allows users to generate radios frequency output frequencies down to 23.5 MHz. For applications requiring isolation the radios frequency output stage can be muted. The mute function can be controlled via pins or software. An auxiliary radios frequency output is also available and can be switched off when not in use. Multifunction design it has point frequency frequency sweeping frequency hopping and other basic functions. Module applications: radios frequency signal frequency generator sensors excitation source line loss attenuation detection scanning clock signal generator. Specifications: Name: Radios Frequency Signal Frequency Generator Model: MAX2870-OLED Supply voltage: DC-5V Module current: 220mA (MAX) Module communication protocol: SPI Module provides routines: STM32F103C8T6; point frequency sweeping frequency Routine platform: STM32F103X-M3. Module reference frequency: 26MHz-TCXO; clock can be input externally Reference frequency signal amplitude: 700mVpp (MIN) Frequency stability: 0.5PPM Phase noise: heterodyne phase noise Module output frequency ranges: 23.5MHz - 6GHz Frequency control step: 0.1MHz Sweeping-step time: 1mS(MIN) Module output power: 5dBm (MAX); output power varies by frequency Module output interface: SMA; 24 hours salt spraying resistance Module output signal: sine or square waves Module output channels: 2 differential channels Module output impedance: 50 ohms matched Module signal characteristics: 23.5MHZ - 3GHz square waves (fundamental frequency) 3GHZ - 6GHz sinewaves (fundamental) Module operating temperature: 0-75°C; civil grade Item size: 101 * 63 * 18mm / 3.98 * 2.48 * 0.71in Item weight: 37g / 1.31ounce Package size: 105 * 100 * 25mm / 4.13 * 3.94 * 0.98in Package weight: 41g / 1.45ounce Packing List: 1 * Radios Frequency Signal Frequency Generator
