Digital single phase 2Wire DIN-Rail 20(80)A Electronic KWh Energy Meter

Features: 35mm standard DIN rail installation in line with standard DIN EN50022. Six-pole width (modulus 12.5mm) in line with standard JB/T7121-1993. Can choose 5+1LCD digital display (99999.1kWh). The standard configuration is a passive (polar) pulse output port and you can choose to add a passive (non-polar) pulse output remote port which conforms to the standard IEC 62053-31. The standard configuration does not detect the direction of load current. You can choose to automatically detect the flowdirection of the load current and be indicated by a single LED. One-way measurement of single-phase two-wire active energy consumption. The direction in which the load current flows does not matter. Comply with standard IEC 62053-21. The standard short terminal cover you can choose to extend the terminal cover to protect the safety of use. Specification: Model: XTM75S-U Accuracy: Level 1 Voltage: 220V Current: 20 (80) A Insulation performance: AC voltage 4kv for 1 minute 1.2 / 50us waveform pulse voltage 6kv Dimensions: 10 x 7.6 cm / 3.94 x 2.99 inches Package Included: 1 x DIN rail electricity meter 1 x manual Note: Due to the difference between different monitors the picture may not reflect the actual color of the item. Thank you! Manual measurement please allow 1-10mm error. Thanks for your understanding.
